Functional Test
OS 4
VV016042, 2021-03-23 / Rev. 09
Undo LASER STOP key (OFF).
Message “Laser emergency
switch activated” disappears,
message “Laser: no fibre detec-
tion” is displayed
Notice: _____________________________________________________________________________
Connect light conductor with laser measurement device to laser probe
connection and confirm message on screen
Message “Laser door interlock
not closed” is displayed
Notice: _____________________________________________________________________________
Plug in DRS (Door Remote Switch) at the device and confirm mes-
sage on screen.
Message “Laser door interlock
not closed” disappears and la-
ser changes to stand-by mode
Notice: _____________________________________________________________________________
Message “Reminder: Laser user
protection” appears
Notice: _____________________________________________________________________________
Laser changes to “Ready” mode
Notice: _____________________________________________________________________________
Notice: _____________________________________________________________________________
Get pedal to position 3 (100%).
Working beam is activated,
sound is correct
Notice: _____________________________________________________________________________
Measure and check the following values at the OS 4 device exit:
Set value to 9
(= 0.7 mW)
