OERTLI OS 4 - Phaco Connector

2021-03-23 / Rev. 10 VV016042 77
11.1.17 Phaco connector
VX400236
Quantity
Description
1
Phaco connector with cable
STEP 1:
1.
2.
Loosen the front enclosure accord-
ing to 11.1.6.
Disconnect the cable from the
power/PCB.
The cable is attached to other ca-
bles. Do not damage these while
cutting the cable ties.
STEP 2:
3.
Unscrew the nut at the phaco
socket and remove the cable.
