10.9 (Power) LEDplus module PCB
(Part of VX210148)
From
To
X1
Core PCB
JP400
X2
Core PCB
JP004
X3
Led PCB
X3
X4
-
-
X5
-
-
X6
Led plus module 180°
-
X7
-
-
X8
Led plus module 90°
-
X9
Led plus module 180°
-
X10
Led plus module 90°
-
