OERTLI OS 4 - Drive for Infusion Pole

2021-03-23 / Rev. 10 VV016042 66
STEP 2:
4.
5.
Remove cable ties.
Disconnect wires from both termi-
nals.
STEP 3:
6.
Loosen the 2 screws that hold the
varistor on the cap rail. Remove var-
istor in a sideways direction.
11.1.10 Drive for infusion pole
VX210126
Quantity
Description
1
Drive for infusion pole
STEP 1:
1.
2.
Remove the isolation transformer
assembly as described in 11.1.9
so that access is granted to the
screws of the lower mounting
bracket.
Remove 2 screws from the lower
mounting bracket.
