OERTLI OS 4 - Components of Posterior Version; Power Ledplus Module

2021-03-23 / Rev. 10 VV016042 95
11.2 Components of posterior version
11.2.1 Power LEDplus module
VX210148
Quantity
Description
1
Power LEDplus module
STEP 1:
1.
Remove 4 screws on the underside.
STEP 2:
2.
Disconnect all cables from the PCB.
Wires are tied together with wire ca-
ble ties – remove them carefully.
STEP 3:
3.
Pull module out of the unit in a side-
ways direction.
Be careful not to damage any wires!
