OERTLI OS 4 - Page 61

2021-03-23 / Rev. 10 VV016042 61
STEP 1:
1.
2.
3.
Remove upper part of IV pole
by turning it counterclockwise.
Unscrew black cap.
Pull black tube, spacer and
gasket over IV pole.
STEP 2:
4.
5.
6.
Remove 4 screws from the upper en-
closure.
Lift upper enclosure over IV pole.
Remove 8 screws from lower enclosure
and pull sheet metal backwards.
There is only one position for cor-
rect mounting of the lower enclo-
sure!
STEP 3:
7.
8.
Remove 8 screws on each side of
the panels.
Pull panel away in a sideways di-
rection.
