OERTLI OS 4 - Page 90

2021-03-23 / Rev. 10 VV016042 90
STEP 2:
2.
Disconnect both cables from core
PCB.
For this purpose, the cover of the
cable duct must be opened.
STEP 3:
3.
4.
Disconnect cable from the pressure
sensor.
Disconnect air tube from the pres-
sure sensor.
Do not break sensor hose inlet by
applying too much force!
STEP 4:
5.
Remove the 4 screws that hold the
complete bracket in place –
2 screws on each side.
