44473001TH Rev.1
219 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
(7) Hold the fuser unit handle and lift the fuser unit out of the MFP.
(8) Remove any jammed paper in the direction of the arrow.
(9) Hold the fuser unit handle and place the fuser unit into the MFP.
(10) Push the locking levers on each side of the fuser unit to the "lock" position.
(11) Hold the blue handles of the image drum unit with both hands and place it into the
MFP.
(1
2) Close the top cover and scanner unit.
Error Code 372
(1) Remove any documents from the document tray.
(2) Open the scanner unit.
(3) Press the top cover open button and open the top cover.
Important To
uch any screw inside the machine to remove static electricity from
your body.
To Next Page
