02 90
Page
1
/4
www.burkert–usa.com
Type 0290 can be combined with...
Type 0290 can be combined with...
Type 0290 can be combined with...
• Universal valve with coupled
diaphragm system
• Switches without differential pressure
• For gases and liquids
• Brass and stainless steel bodies
• Seal material NBR, EPDM and FKM
• Approvals:
2/2-way Solenoid Valve
for gases and fl uids
Pilot-controlled normally–closed valve with
servo-diaphragm, forced valve lifting and
coupled magnetic system. The valve switches
without differential pressure from 0 bar with gases
and liquids.
Power consumption
Orifice Inrush Hold
UC UC
UC UC
UC UC
[mm] [W] [W]
[mm] [W] [W]
[mm] [W] [W]
12 80 6
12 80 6
12 80 6
20 – 40 100 9
20 – 40 100 9
20 – 40 100 9
50 30 30
50 30 30
50 30 30
Type 1078
Timer unit
Type 2511
ASI cable plug
Type 8600
Dosing control
Type 2508
Cable plug
F M
Technical data
Orifi ce
7/16” – 2” (DN 12 – 50 mm)
Body material
Brass, stainless steel 1.4581
Internal parts of valve
See drawing on page 2
Seal material
NBR, FKM, EPDM
Media
NBR
FKM
EPDM
Neutral media, compressed air, water, hydraulic oil
Per-solutions, hot oils, oxygen
Oil and fat-free media, e.g., hot water
Media temperature
for NBR
for FKM
for EPDM
14
°F
to 176°F (–10
°C
to +80°C)
32
°F
to 248°F (0
°C
to +120°C)
–22
°F
to 248°F (–30
°C
to +120°C)
Ambient temperature
Max. 131°F (+55°C)
Voltage tolerance
±10%
Duty cycle
100% continuous cycle
Electrical connection
Cable plug for Ø 7 mm cable (supplied as standard)
Protection class
IP 65 with cable plug
Installation
As required, preferably with actuator upright
