The Ultimate Ice Resurfacer 89
Picture 1: Conditioner lift arm block left side
Picture 2: Conditioner lift arm block right side
Picture 3: Conditioner mount pins left and right sides
Picture 4: Board brush arm pivot and shaft
Picture 5: Blade holder pivot and horizontal auger bearing left side
Picture 6: Blade holder pivot and horizontal auger bearing right side
Picture 7: Blade adjustment screw,
Picture 8: Upper and lower king pin left side
Picture 9: Front axle center pivots
Picture 10: Upper and lower king pin right side
Picture 11: Snow dump tank cover pivot left side
Picture 12: Snow dump tank cover pivot right side
Picture 13: Snow dump tank pivot left side
Picture 14: Snow dump tank pivot right side
Picture 15: Upper bearing blade adjustment handle
Picture 16: Lower bearing blade adjustment wheel
Picture 17: Universal joint blade adjustment crank
Picture 18: Front bumper wheel
Picture 19: Parking brake linkage pivots on rear axle
8.2.8 Every 3 Years
• Change the wheel drive gear box oil (Dexron III)
• Change the hydraulic oil and lter
To put the OLYMPIA back into operation at the beginning of the season, perform the weekly
maintenance procedure
19
