EnForcer™ SCR Service Manual I.B. 1561
14
If Cool Down is selected, at the end of charge the display will read:
Cool Down
In: 00:59
For the duration of the cool down period. After the cool down period has expired, the display will read “Done/Battery
Available”.
8. When the battery is disconnected, only the POWER LED remains lit and the display will return to “Connect
Battery” / Time/ Date alternately. The charge counter is incremented by one for the completed charge cycle.
USER PARAMETER CONFIGURATION
ENTER USER PARAMETERS
The charger’s User parameters may only be configured while the charger is in idle mode with no battery connected.
Press Equalize button and hold for approximately 5 seconds. The display will show: “User Parameters”. Release the
Equalize button and the first User parameter: “Set Clock/Calendar?” is displayed.
ADJUSTING USER SETTINGS:
Toggle the UP or DOWN arrow keys to scroll through the available User Parameters. To view the contents of the
variable displayed, toggle the Equalize button. The value of that setting will be displayed. To change the displayed
value, toggle the UP or DOWN arrow keys to the desired value. If you press and hold the UP or DOWN pushbuttons
for 3 seconds when adjusting the parameters, the options will scroll through at a rapid pace. Release the pushbutton
to return to normal scrolling mode. Once the desired value is chosen for that parameter, toggle the Equalize button
again to set it and to move on to the next parameter. In the case of setting the real time clock, toggle the Equalize
button when “Set Clock/Calendar?” is displayed in order to enter the clock setting function. Clock Minutes is now
displayed. Choose the Clock Minutes by toggling the Equalize button again. To change Clock Minutes, scroll with
the UP or DOWN arrows. Press Equalize again to set the value. Scroll through the other real time clock value of
hours, days etc. by toggling the UP or DOWN arrow keys and set in a similar fashion. Press the Start/Stop key to
save and exit the real time clock function.
To exit and save from User Parameters at any time, press the Start/Stop button. For a list of available user
parameters and their definitions, see the table below.
Parameters Description Range
Default
Battery
Selection
Select Battery 1-3
When Battery Select is enabled in Service Parameters, choose
between 1,2 or 3 completely different battery and charge profiles.
NOTE: This parameter is displayed when Battery Select is
enabled in Service Parameters.
1-3 1
Set
Clock/Calendar
Minute, Hours, Date etc.
Enter the set clock function to adjust the time/date.
This should be set to match current Date/Time
various none
Battery Cell
Size
Battery Cell Size
Select the battery cell size to be charged. This value can be less
than or equal to the Charger nameplate cell size.
Do not adjust unless order acknowledgement specifies a change.
1-Charger
nameplate
cell size
18
Battery Amp-
Hours
Battery Amp Hour
Select the battery amp hour value. This value can be less than or
equal to the Charger nameplate amp hour value.
Do not adjust unless order acknowledgement specifies a change.
10 –
Charger
nameplate
amp hour
850
To Next Page
