EnForcer™ SCR Service Manual I.B. 1561
15
Contrast
Adjust
Contrast Adjust
Select the LCD contrast between characters and background.
Do not adjust unless order acknowledgement specifies a change.
10-1100 100
Display Mode
Display mode
The following selection determines the parameters that are
displayed during the charge cycle.
3 = displays current, A-H retuned, charge time and battery voltage
2 = displays current and voltage only
1 = displays current only
0 = displays voltage only
Do not adjust unless order acknowledgement specifies a change.
0-3
3
Delayed Start
Delayed start
Amount of time delay after a battery is connected to the charger,
before charging proceeds. Increments in 1 minute intervals.
Do not adjust unless order acknowledgement specifies a change.
0 min – 25
hr
.00
Cooldown
Time
Cool Down Time
Amount of time after a complete charge cycle that a battery needs to
cool down before being utilized.
Do not adjust unless order acknowledgement specifies a change.
0 hr – 12
hr
1.00 hr
Equalize Count
Equalize Counts
Total amount of charge cycles that need to occur before an
automatic equalize charge cycle will take place. Charge cycle must
be 1 hour minimum duration.
(0 indicates that no Equalize charge will occur)
Do not adjust unless order acknowledgement specifies a change.
0(OFF)
1-20
charge
cycles
5 charge
cycles
SERVICE PARAMETERS
While in Idle Mode, hold down the DOWN and EQUALIZE buttons until the display reads Service Parameters (approximately 10
seconds).
Release the buttons and the display will read Charger Cell Size, Range: 1- 40 Cells.
Toggle the UP or DOWN arrow keys to scroll through the available Service parameters. To view the contents of the variable
displayed, toggle the EQUALIZE button. The value of that setting will be displayed. To change the displayed value, toggle the UP
or DOWN arrow keys to the desired value. If you press and hold the UP or DOWN pushbuttons for 3 seconds when adjusting the
parameters, the options will scroll through at a rapid pace. Release the pushbutton to return to normal scrolling mode. Once the
desired value is chosen for that parameter, toggle the EQUALIZE button again to set it and to move on to the next parameter. To
save and exit from Service parameters at any time, press the START/STOP button.
The table below shows a list of the available Service parameters, their meanings, and allowed values. The table shows the
Service parameters in the order that they appear.
Parameter
Description Range Default
C h a r g e r C e l l
S i z e
Charger Cell Size
This is the maximum number of cells that the charger is designed to
charge.
This should be set to match the cell size rating on the charger
nameplate.
1 - 40
18
C h a r g e r
A m p - H o u r s
Charger Amp-Hours
This is the maximum amp-hour rating of the charger.
This should be set to match the amp-hour rating on the charger
nameplate
10 – 2500 850
