EnForcer™ SCR Service Manual I.B. 1561
16
T i m e t o
G a s s i n g
Time to Gassing Limit
If the battery does not reach the gassing voltage within this time (in hours
and minutes), the charger will shut off.
Do not adjust unless order acknowledgement specifies a change.
:01 – 12:00
6:00
C h a r g e T i m e
L i m i t
Charge Time Limit
If the charge is not complete within this time (in hours and minutes), the
charger will shut off and indicate fault.
Do not adjust unless order acknowledgement specifies a change.
:01 – 18:00 14:00
R e f r e s h
T i m e
Refresh Charge Time
Length of refresh charge, in hours and minutes.
Do not adjust unless order acknowledgement specifies a change.
:00 – 1:00 :20
R e f r e s h
I n t e r v a l
Refresh Interval
Length of time between refresh charges, in hours and minutes.
Do not adjust unless order acknowledgement specifies a change.
2:00 – 99:00 24:00
E q u a l i z e
D u r a t i o n
Equalize Time
Length of time to run in equalize, in hours and minutes.
Do not adjust unless order acknowledgement specifies a change.
:06 – 10:00 3:00
G a s s i n g
V o l t a g e
Gassing Voltage
Set point for gassing (80% point) voltage, in volts per cell.
Do not adjust unless order acknowledgement specifies a change.
1.00 – 3.00 2.370
- d v d t ( -
v o l t a g e
/ t i m e )
Negative dV/dt Voltage
Set point for negative dV/dt voltage, in millivolts per cell. Used for hot
battery or bad cell detection.
Do not adjust unless order acknowledgement specifies a change.
0 - 100 20
U p B a t t e r y
D e t e c t
Up Battery Time
If battery reaches gassing voltage before this time, in minutes, has expired,
the charger will stop and go to complete.
Do not adjust unless order acknowledgement specifies a change.
:00 - :10 :02
C a b l e
L e n g t h
Cable Length
Length of battery cables, in inches, installed on the charger – used in
battery cable drop compensation calculations.
This should be set to match the length of the cables installed on the
charger.
0 - 2400
120
C a b l e T y p e
Cable Type
Size of battery cable:
1 = 4/0 cable
2 = 3/0 cable
3 = 2/0 cable
4 = 1/0 cable
5 = #2 cable
This should be set to match the type of cable installed on the charger.
1 - 5 4
C a b l e
C o n f i g u r a t i o
n
Cable Configuration
This parameter configures the controls to the configuration of the battery
cables for the purposes of calculating the battery cable drop compensation:
0 = Cable drop compensation disabled.
1 = Standard cable
2 = Parallel cable
This should be set to match the configuration of the cables installed
on the charger.
0 - 2 1
T e r m i n a t i o n
M e t h o d
Termination Method
Method used to finish charge:
1 = dV/dt
2 = time-voltage
3 = both dV/dt and time-voltage (whichever occurs first)
4 = proportional
5 = amp-hour
1 – 5 2
A m p - H o u r s
R e m o v e d
Amp Hours Removed
If Amp-Hours Termination Method is chosen above. This parameter sets
the Amp-hours removed.
Do not adjust unless order acknowledgement specifies a change.
10-2500 850
E x t e n d e d
d v d t
Adds a specified time to the dV/dt termination method if dv/dt termination is
0:00 – 4:00 0:00
