EnForcer™ SCR Service Manual I.B. 1561
17
chosen above.
Do not adjust unless order acknowledgement specifies a change.
D e l t a
V o l t a g e -
d v / d t
Delta Voltage- dv/dt
The change in battery voltage over time limit that the charger monitors, in
order to determine charge completion. Units are in mV/cell. High values
correspond to a shorter charge cycle.
Do not adjust unless order acknowledgement specifies a change.
0-50 10
T i m e a f t e r
G a s s i n g
Time after Gassing Voltage
Time limit for time-voltage and Both termination modes (see above).
Do not adjust unless order acknowledgement specifies a change.
0:00 – 10:00 5:00
P r o p o r t i o n a l
F a c t o r
Proportional Factor
For proportional termination mode, this parameter specifies the percentage
of start rate time to continue charging after reaching gassing voltage.
Do not adjust unless order acknowledgement specifies a change.
0 – 100 40
F i n i s h
C u r r e n t
Finish Current
Setting for finish rate current in amps. This is automatically set to 4.5% of
battery amp-hours when either battery amp-hours or charger amp-hours is
set. If Sealed profile is chosen (VRLA), then this value is set to 2.5% of
battery amp-hours. The maximum setting is 16% of charger nameplate
amp-hours.
Do not adjust unless order acknowledgement specifies a change.
3 – 200 38
S t a r t
C u r r e n t
Start Current
Setting for start rate current in amps. This is automatically set to 16% of
battery amp-hours when either battery amp-hours or charger amp-hours is
set. The maximum setting is 16% of charger nameplate amp-hours.
Do not adjust unless order acknowledgement specifies a change.
3 – 400 136
C h a r g e
P r o f i l e
Charge Profile
1 = IEI (flooded)
2 = IEIE (sealed- VRLA)
3= AGV ( Auto guided vehicle)
4= I (VVR) 5 = IE ( Floating mode )
6= Opportunity
This should be set to match the type of battery that the charger will be
charging.
1 – 6 1
S e a l e d
F i n i s h V o l t s
Sealed Finish Volts
For sealed (VRLA) charge profiles, the final voltage, in volts per cell.
Do not adjust unless order acknowledgement specifies a change.
1.000 –
3.000
2.530
S e a l e d
F i n i s h T i m e
Sealed Finish Time
For sealed (VRLA) charge profiles, the maximum time to stay in the final
voltage stage.
Do not adjust unless order acknowledgement specifies a change.
0:00 – 12:00 2:00
E q u a l i z e o n
D a y 1
Equalize on Day 1
Equalize on a particular day of the week after charge cycle completes. Set
from Sunday – Saturday or OFF. Used in conjunction with the real-time-
clock. Will disable Equalize by Count in USER Parameters when ON.
Do not adjust unless order acknowledgement specifies a change.
Sunday-
Saturday or
OFF
OFF
E q u a l i z e o n
D a y 2
Equalize on Day 2
Second day equalize setting similar to above. Equalize on a particular day
of the week after charge cycle completes. Set from Sunday – Saturday or
OFF. Used in conjunction with the real-time-clock. Will disable Equalize by
Count in User Parameters when ON.
Do not adjust unless order acknowledgement specifies a change.
Sunday-
Saturday or
OFF
OFF
B l o c k O u t
t i m e S t a r t
Block out Start Time
Start time for charger block out period. Setting 00:00 is OFF.
Do not adjust unless order acknowledgement specifies a change.
00:00(OFF)
00:01-23:59
00:00
B l o c k O u t
t i m e S t o p
Block out Stop Time
Stop time for charger block out period. Setting 00:00 is OFF.
Do not adjust unless order acknowledgement specifies a change.
00:00(OFF)
00:01-23:59
00:00
E n a b l e
F o r c e d S t a r t
Enable Forced Start
Enable/Disable the charger control forced start function.
Do not adjust unless order acknowledgement specifies a change.
0(OFF)
1(ON)
1
