The Ultimate Ice Resurfacer 60
Test drive the OLYMPIA doing a dry cut. If the blade is properly set up you will see a feathered
edge on the ice surface on both sides of the conditioner. If the feathered edge on both sides of
the conditioner is not an equal distance from the runners on both sides of the conditioner, stop,
dismount, and adjust the driver’s side , up or down, until the feathered edge is equal distance
from the runners on both sides of the conditioner.
After the blade angle and level are set, any change in the cutting depth will alter the indicator
arm position in the sight hole, but blade angle tolerances will accommodate such adjustment
and further adjustment of the blade angle will not be necessary.
6.4 Horizontal and Vertical Augers
The horizontal auger in the conditioner carries the snow scraped o the ice by the blade into
the centre of the conditioner where a vertical auger picks it up and transports it to the snow
bin in the front of the OLYMPIA.
6.4.1 Horizontal Auger Adjustment
The horizontal auger should be approximately 1/8th” (3mm) above the bottom of the runners
to maximize snow pick up while at the same time preventing any marking of the ice surface.
Feathered Edge
