The Ultimate Ice Resurfacer 61
Auger Height Adjustment
The horizontal auger is adjusted by loosening the four outer bolts on the bearing adjustment
plate on each end of the auger and the four bolts for the auger motor mount. This can be
checked by running a piece of string between the runners and observing the distance between
the string and the auger.
Pry the auger to the proper position.
After the adjustment has been completed, re-tighten the four outer bolts on the bearing
adjustment plate.
If the auger is set too low, diagonal lines may be found where the auger touches the ice.
If the auger is set too high, excessive amounts of snow will be left on the ice surface at the end
of the resurfacing.
Loosen Outer Bolts
