Page 3/4
0290
Solenoid valves Dimensions [mm]
Threaded
port
Dimensions [mm]
according to DIN 2501
DN
D
B
E
F
H
J
L
12
NPT 1/2
95.5
40
14
40
73.0
74.5
20
NPT 3/4
122.0
60
16
49
86.5
100.0
25
NPT 1
131.0
70
18
49
91.5
115.0
32
NPT 1 1/4
145.0
85
20
49
99.0
126.0
40
NPT 1 1/2
154.0
85
22
49
99.0
126.0
50
NPT 2
211.0
115
24
72
126.0
164.0
Material
Coil: Epoxy
Stopper: 1.4105
Shading ring: Brass version: copper
(
only AC version) Stainless steel version: silver
Spring: 1.4310
Magnetic core: 1.4105
Guide tube 1.4303
O– ring: (see ordering chart)
Seat seal (see ordering chart)
Diaphragm support Brass version: CuZn39983
disc Stainless steel version: 1.4401
Diaphragm (see ordering chart)
Pilot seat Brass version: CuZn39983
Stainless steel version: 1.4401
Body Brass or stainless steel
Brass
resp. 1.4581
