Olympia Millennium-E - Page 232

Main
Panel
PBM1
M1
M1, M3 & Pump motor leads
M3
M1 Motor Leads
M1 Motor RTD
4 CONDUCTOR SHIELDED CABLE - 570 cm
AWG 16 - BLACK - 570 cm
AWG 16 - RED - 570 cm
AWG 8 - RED - 570 cm
AWG 8 - BLUE - 570 cm
AWG 8 - WHITE - 570 cm
Front bumber harness branches off and
through PBM1 box without interruption
M3 Motor Leads
Pump Motor Leads
M3 Motor RTD
Pump Motor RTD
Pump Motion control M3 Motion control
M1 Motion control
4 COND SHLD CABLE - 210 cm
AWG 16 - BLACK - 210 cm
AWG 16 - RED - 210 cm
4 COND SHLD CABLE - 195 cm
AWG 16 - BLACK - 195 cm
AWG 16 - RED - 195 cm
AWG 8 - RED - 195 cm
AWG 8 - BLUE - 195 cm
AWG 8 - WHITE - 195 cm
AWG 8 - RED - 210 cm
AWG 8 - BLUE - 210 cm
AWG 8 - WHITE - 210 cm
M1 leads, RTD and motion control wires go
continues through PBM1
Pump Motion control
M3 Motion control
M1 Motion control
SHIELD
BROWN
WHITE
YELLOW
GREEN
SHIELD
BROWN
WHITE
YELLOW
GREEN
SHIELD
BROWN
WHITE
YELLOW
GREEN
SHIELD
BROWN
WHITE
YELLOW
GREEN
SHIELD
BROWN
WHITE
YELLOW
GREEN
SHIELD
BROWN
WHITE
YELLOW
GREEN
Red & Black
Red & Black
Red & Black
