Olympia Millennium-E - Page 234

Keyswitch
Direction switch
Footbrake
COMSYS
Parkbrake
2
1
2 RD3 WH / BK
4
3
1 RD / WH3 WH / BK
4 BK
4 BK
6 YL
5 WH
A B C
52 PK
49 BK
53 YL / RD
46 GN
45 RD
47 BK
48 BU
47 BK
jumper
A B C
52 PK
49 BK
51 PU
Large connector under seat
A
49
BK
R
B
50
GY
Q
H
58
YL / BK
K
62
OR / BK
I
59
YL / BK
J
60
BU / WH
S
O
66
BK
T
N
65
BK / WH
V
U
P
L
63
GN
C
54
BK
G
57
PK
D
55
BR / WH
E
56
RD / YL
F
57
PK
M
64
YL
(Part of Main Harness - gasketed side w.female pins)
Jumper
(Part of Main Harness - male pins)
(Part of Main Harness - male pins)
(Part of Main Harness - male pins)
