The Ultimate Ice Resurfacer 44
The water hose behind the solenoid valve should not be too big in relation to the water
pressure and pipe size, because a pressure dierence of 0,5 bar (7 psi) is needed to close the
solenoid valve.
The solenoid valve of the cold water supply line is connected at the Wash Water panel. To
switch the wash water supply ON or OFF, turn the switch (Fig. 5.5, Item 22) in the appropriate
direction.
The lling procedure can be interrupted or stopped at any time by turning the selector switch
to the OFF position.
The control panel function can be used even when the ignition key is turned o, provided the
battery connector is plugged in.
Connection of the Wash Water Line
First connect the water line to the water-lling inlet and then connect the solenoid valve to
the supply socket on the panel. When the water tank is full, the solenoid valve automatically
turns o the water.
Always be sure to insert the ll hose into the ice resurfacer rst.
