The Ultimate Ice Resurfacer 46
The accelerator pedal must not be pressed when you turn on the ice resurfacer, otherwise
the controller will assume there is a fault and will not turn on.
Before pressing the accelerator pedal, it is essential that you rst turn on the ignition with
the key. And when ready select the direction in which you want to travel.
Brake Pedal
The left foot pedal is the main brake pedal. The foot brake acts simultaneously on all four
drive wheels. ABS is not installed. The OLYMPIA braking system has a pressure accumulator, so
that the brakes can be applied at least another two times after the hydraulic system has been
switched o.
Parking Brake Lever
The parking brake lever (hand brake) is located at the right of the driver’s seat. It acts on
the two rear wheels. If movement of the ice resurfacer is started while the parking brake is
applied, the controller switches to CREEP MODE (very low speed) to keep from damaging the
wheel drive motors.
