Item
Specifications
DP22 DP27
Image size
1920 x 1440 (1 x 1)
960 x 720 (1 x 1)
960 x 720 (2 x 2)
Cutout of any size at any position
2448 x 1920 (1 x 1)
1224 x 960 (1 x 1)
1224 x 960 (2 x 2)
Cutout of any size at any position
File format TIFF (no compression) JPEG-LOW (compression rate: 1/2.7) JPEG-HIGH (compression
rate: 1/8)
Number of pixel for display 1920 x 1200 WUXGA
1920 x 1080 Full HD
1680 x 1050 WSXGA+
1280 x 854
1280 x 768 WXGA
1024 x 600 WSVGA
1600 x 1200 UXGA
1280 x 1024 SXGA
1280 x 960 QVGA
1024 x 768 XGA
Live image display speed
(frame rate)
Displayed pixels 1920 x 1440 (1 x 1) :
25 fps
Displayed pixels 960 x 720 (1 x 1) :
25 fps
Displayed pixels 960 x 720 (2 x 2) :
25 fps
Displayed pixels 1920 x 1080 :
30 fps
Displayed pixels 2448 x 1920 (1 x 1) :
15 fps
Displayed pixels 1224 x 960 (1 x 1) :
30 fps
Displayed pixels 1224 x 960 (2 x 2) :
30 fps
Displayed pixels 1920 x 1080 :
22 fps
Image display
(zooming
magnification)
Live image
display
1x, 2x (digital zoom), 4x (digital zoom), 1:1
Played image Thumbnail view 1x, 2x, 4x, 1:1
Scale display Scale imprint function : View scale / Hide scale
Available microscope total magnification : 00.01 - 9999.99 x
} Up to 28 types of total magnifications can be set.
Measurement functions Distance between 2 points, Polyline, 3 points circle, Distance between 2 centers,
3 points angle, 4 points angle, Perpendicular, Parallel line distance, Polygon area, Free
line, XY distance, Distance between 2 cross lines, Ruler, Arrow, Count, Text
} To display measurement results more accurately, followings must be set.
· Scale display : ON
· Scale setting : Entry of objective power
· Image file format : TIFF (applicable for still image measurement in PLAY mode)
Recording media USB storage device, PC connected to network
Input/output connectors DC input : Main power supply
Camera : USB3.0 TypeA
Interface : USB2.0, USB3.0
Monitor output : DVI-I (Digital / Analog RGB)
Wired LAN : 100Base-TX /10Base-T
Serial ports : RS-232C, D-SUB9pin
Microphone input connector : stereo mini jack
Line output connector : stereo mini jack
Dimensions and weight
180 (W) x 47 (H) x 215 (D) mm 1600 g
10 Specifications
