Olympus DP2-SAL - Nomenclature of respective portions; 2-1 Hardware controls

DP2-SAL
9
2 Nomenclature of respective portions
Interface cable
Control box D2-CB
Front
Back
2-1 Hardware controls
USB connector (USB2.0)
USB connector (USB2.0)
CAMERA connector
(USB3.0 connector)
USB3.0 connector
DC input connector
Line output connector
Microphone input connector
Main switch
Display connector
DVI-I/-D/-A
Camera head
Control box
D2-CB
RS-232C connector
For connecting control box
(U-CBS, etc.) (P.90)
LED
Cable holderLAN cable connector
