Setting display target of scales and cross lines
When the display of scales or cross lines is set to ON, you can select
from 2 types described below.
Button Function
Live Scales and cross lines are displayed only on the
live image. (Scales or cross lines are not drawn on
the acquired image.)
Live/Snap Scales and cross lines are displayed on the live
image and also on the still image.
} These settings are also used for displaying measurements.
Select the [Play] tab
a
.
Press the [Measure] button
b
. The window changes to the
[Measurement] window.
Select the [Display on] button
c
.
1
2
3
a
b
