Olympus DP2-SAL - Media setup

DP2-SAL
43
4
Setting image orientation
The orientation of the image to be shown on the display can be set
to either one of the followings. This operation is not available while
saving the acquired image.
Button Function
Erect
180° rotated
Left/Right inverted
Up/Down inverted
Select the [Menu] tab
a
and select the [Display] tab
b
in the tab
displayed.
Press the [Image orientation]
c
button to select.
1
2
5
Setting focus indicator
You can select to Show or Hide the focus indicator and the focus area.
Select the [Menu] tab
a
and select the [Display] tab
b
in the tab
displayed.
Press following buttons of [Focus Indicator]
c
to select Show or Hide.
Button Function
OFF The focus indicator and the focus area are not
displayed.
INDICATOR Only the focus indicator is displayed.
INDICATOR &
AREA
Both the focus indicator and the focus area are
displayed.
1
2
a
a
b
b
c
c
