Olympus DP2-SAL - 6 Setting network

78
You can set the language you use. The language can be selected
from 2 languages: Japanese or English.
Select the [Menu] tab
a
and select the [Setting] tab
b
in the tab
displayed.
Use the [Language]
c
button to select.
1
2
1
Setting the language
b
c
2
Setting the microscope
You can set the adapter lens magnification, the objective magnification
and the zoom/magnification changer which are required for displaying
the scale in an appropriate length.
} When the control box (U-CBS, etc.) is connected, the setting
procedures will be different. Refer to "Automatic scale change (P. 92)".
Select the [Menu] tab
a
and select the [Maintenance] tab
b
in the
tab displayed.
Press the [Microscope] button
c
of [Calibration]. The [Microscope
setting] wizard is displayed.
1
2
a
a
b
c
d
e
The message shown on the left appears. Confirm the content and
press the [OK] button
d
.
When settings are changed, the control box D2-CB
restarts automatically. It takes several minutes because
the control box restarts twice. Do not turn OFF the
main switch or unplug the AC adapter until the restart
completes.
3
CAUTION
If the recording media such as a USB memory, etc. are connected
to the control box D2-CB, the message shown on the left appears.
Disconnect the recording media and press the [OK] button
e
.
When setting the language, disconnect the recording
media connected to the control box D2-CB such as a
USB memory, etc. until the restart (automatic) after settings
is completed.
4
CAUTION
