OM SYSTEM LS-P5 - External Input Devices

53
EN
2
Recording
Record sound from an external microphone or audio device connected via the voice
recorder’s microphone/line jack ( ).
Choosing an Input Device
Select [Microphone] for input devices with microphone connectors, [Line In] for audio
devices or other equipment with line-in connectors.
NOTE
• If the microphone/line-in setting does
not match the type of plug used to
the connect the device, sound may
recorded at a volume that is too high
or too low.
1
During recording or while the
voice recorder is in stop mode,
press the MENU/SCENE
button.
2
Press the + or − button to
select the [Rec Menu] tab.
3
Press the `OK button to
move the cursor into the list of
setting items.
4
Press the + or − button to
select [External Input].
5
Press the `OK button.
6
Press the + or − button to
select [Microphone] or [Line
In].
Recording Using External Mics or Other Input
Devices Connected to the Recorder [External Input]
