© 2011 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev F
CT PC E-Box 6-13
Remove/Replace the Power Supply
2. Remove the screw that secures the power supply to the E-Box base.
Figure 6-18. Remove the screw that secures the power supply to the E-Box
3. Pull the power supply away from the E-Box wall.
4. Lift, but do not remove, the power supply from the E-Box.
To Next Page
