6-14 CT PC E-Box
Remove/Replace the Power Supply
OmniRx Service Guide/67-2023 Rev F © 2011 Omnicell, Inc.
Figure 6-19.
Figure 1-19.
Power supply power cable
5. Remove the power cable connected to the power supply.
Figure 6-20. Disconnect the power cable from the power supply
6. Remove the power supply from the E-Box.
Caution:
Pulling the power supply too far from the E-Box could damage the power supply
To Next Page
