Block Programming Instructions Section 3-30
Variations
Applicable Program Areas
Note EXIT(806) and EXIT NOT(806) must be used in block programming regions
even within subroutines and interrupt tasks.
Operand Specifications
Variations Always Executed in Block Program EXIT(806)
EXIT(806) B
EXIT NOT(806) B
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area B
CIO Area CIO 0.00 to CIO 6143.15
Work Area W0.00 to W511.15
Holding Bit Area H0.00 to H511.15
Auxiliary Bit Area A0.00 to A959.15
Timer Area T0000 to T4095
Counter Area C0000 to C4095
Task Flags TK00 to TK31
Condition Flags ER, CY, >, =, <, N, OF, UF, >=, <>, <=, ON, OFF, AER
Clock Pulses 0.02 s, 0.1 s, 0.2 s, 1 s, 1 min
DM Area ---
Indirect DM addresses
in binary
---
Indirect DM addresses
in BCD
---
Constants ---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
