Block Programming Instructions Section 3-30
3-30-7 TIMER WAIT: TIMW(813) and TIMWX(816)
Purpose Delays execution of the rest of the block program until the specified time has
elapsed. Execution will be continued from the next instruction after
TIMW(813)/TIMWX(816) when the timer times out.
Ladder Symbol PV Refresh Method: BCD
PV Refresh Method: Binary
Variations
Applicable Program Areas
Note TIMW(813)/TIMWX(816) must be used in block programming regions even
within subroutines.
Operands N: Timer Number
BCD: 0 to 4095 (decimal)
Binary: 0 to 4095 (decimal)
S: Set Value
BCD: #0000 to #9999 (BCD)
Binary: &0 to &65535 (decimal)
#0000 to #FFFF (hex)
Operand Specifications
TIMW(813) N
SV
N: Timer number
SV: Set value
TIMWX(816) N
SV
N: Timer number
SV: Set value
Variations Always Executed in Block Program
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK Not allowed.
Area N SV
CIO Area --- CIO 0 to CIO 6143
Work Area --- W0 to W511
Holding Bit Area --- H0 to H511
Auxiliary Bit Area --- A0 to A447
A448 to A959
Timer Area 0000 to 4095 T0000 to T4095
Counter Area --- C0000 to C4095
DM Area --- D0 to D32767
Indirect DM addresses
in binary
--- @ D0 to @ D32767
Indirect DM addresses
in BCD
--- *D0 to *D32767
Constants --- BCD:
#0000 to 9999 (BCD)
ā&ā cannot be used.
Binary:
&0 to &65535 (decimal)
#0000 to #FFFF (hex)
Data Registers --- DR0 to DR15
