Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Comparison Instructions
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
Input Comparison
Instructions
(unsigned)
LD, AND, OR += 300 4 0.35 6.0 ---
LD, AND, OR + <> 305
LD, AND, OR + < 310
LD, AND, OR +<= 315
LD, AND, OR +> 320
LD, AND, OR +>= 325
Input Comparison
Instructions (double,
unsigned)
LD, AND, OR +=+L 301 4 0.35 6.9 ---
LD, AND, OR +<>+L 306 ---
LD, AND, OR +<+L 311 ---
LD, AND, OR +<=+L 316 ---
LD, AND, OR +>+L 321 ---
LD, AND, OR +>=+L 326 ---
Input Comparison
Instructions (signed)
LD, AND, OR +=+S 302 4 0.35 9.8 ---
LD, AND, OR +<>+S 307
LD, AND, OR +<+S 312
LD, AND, OR +<=+S 317
LD, AND, OR +>+S 322
LD, AND, OR +>=+S 327
Input Comparison
Instructions (double,
signed)
LD, AND, OR +=+SL 303 4 0.35 10.5 ---
LD, AND, OR
+<>+SL
308
LD, AND, OR +<+SL 313
LD, AND, OR
+<=+SL
318
LD, AND, OR +>+SL 323
LD, AND, OR
+>=+SL
328
Time Comparison
Instructions
LD, AND, OR +DT 341 4 18.8 53.3 ---
LD, AND, OR +<>DT 342 4 45.6 53.3 ---
LD, AND, OR +<DT 343 4 45.6 53.3 ---
LD, AND, OR +<=DT 344 4 18.8 53.2 ---
LD, AND, OR +>DT 345 4 45.6 53.4 ---
LD, AND, OR +>=DT 346 4 18.8 53.1 ---
COMPARE CMP 20 3 0.10 4.0 ---
!CMP 20 7 +45.2 +17.4 Increase for immediate refresh
DOUBLE COMPARE CMPL 60 3 0.50 4.8 ---
SIGNED BINARY
COMPARE
CPS 114 3 0.3011.6---
!CPS 114 7 +45.2 +32.5 Increase for immediate refresh
DOUBLE SIGNED
BINARY COMPARE
CPSL 115 3 0.50 12.5 ---
TABLE COMPARE TCMP 85 4 27.66 32.2 ---
MULTIPLE
COMPARE
MCMP 19 4 42.33 52.4 ---
UNSIGNED BLOCK
COMPARE
BCMP 68 4 47.21 45.8 ---
