Omron CP - PROGRAMMING MANUAL 05-2007 - Page 1102

1069
Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Timer and Counter Instructions
CONDITIONAL
JUMP NOT
CJPN 511 2 0.95 4.3 When JMP condition is satisfied
MULTIPLE JUMP JMP0 515 1 0.15 1.0 ---
MULTIPLE JUMP
END
JME0 516 1 0.15 3.4 ---
FOR LOOP FOR 512 2 1.00 6.2 Designating a constant
BREAK LOOP BREAK 514 1 0.15 3.4 ---
NEXT LOOP NEXT 513 1 0.45 4.8 When loop is continued
0.55 4.8 When loop is ended
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
TIMER TIM --- 3 1.30 6.4 ---
TIMX 550
COUNTER CNT --- 3 1.30 6.7 ---
CNTX 546
HIGH-SPEED
TIMER
TIMH 15 3 1.80 6.4 ---
TIMHX 551
ONE-MS TIMER TMHH 540 3 1.75 6.4 ---
TMHHX 552
ACCUMULATIVE
TIMER
TTIM 87 3 24.81 12.9 ---
17.79 11.7 When resetting
13.97 10.2 When interlocking
TTIMX 555 23.78 14.2 ---
17.76 11.6 When resetting
14.11 10.1 When interlocking
LONG TIMER TIML 542 4 15.69 13.2 ---
13.61 11.5 When interlocking
TIMLX 553 17.51 14.6 ---
13.11 11.2 When interlocking
MULTI-OUTPUT
TIMER
MTIM 543 4 35.36 14.2 ---
12.81 7.6 When resetting
MTIMX 554 41.95 27.8 ---
17.42 11.5 When resetting
REVERSIBLE
COUNTER
CNTR 12 3 29.03 14.5 ---
CNTRX 548 22.44 14.3
RESET TIMER/
COUNTER
CNR 545 3 15.27 10.9 When resetting 1 word
5.95
ms
2.70
ms
When resetting 1,000 words
CNRX 547 14.44 10.9 When resetting 1 word
5.95
ms
2.70
ms
When resetting 1,000 words
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution
time (µs)
Conditions
CP1H CP1L
