Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Logic Instructions
DATA ENCODER DMPX 077 4 11.90 14.4 Encoding 1 digit (16 to 4)
58.70 24.1 Encoding 4 digits (16 to 4)
19.76 16.9 Encoding 1 digit (256 to 8)
80.32 16.9 Encoding 2 digits (256 to 8)
ASCII CONVERT ASC 086 4 12.49 12.1 Converting 1 digit into ASCII
18.03 20.0 Converting 4 digits into ASCII
ASCII TO HEX HEX 162 4 12.64 15.6 Converting 1 digit
COLUMN TO LINE LINE 063 4 34.95 28.4 ---
LINE TO COLUMN COLM 064 4 42.09 40.4 ---
SIGNED BCD-TO-
BINARY
BINS 470 4 15.73 15.7 Data format setting No. 0
15.93 15.7 Data format setting No. 1
15.93 15.9 Data format setting No. 2
16.00 16.0 Data format setting No. 3
DOUBLE SIGNED
BCD-TO-BINARY
BISL 472 4 18.59 17.4 Data format setting No. 0
18.66 17.5 Data format setting No. 1
18.41 17.7 Data format setting No. 2
18.47 17.7 Data format setting No. 3
SIGNED BINARY-
TO-BCD
BCDS 471 4 13.16 17.4 Data format setting No. 0
13.18 17.5 Data format setting No. 1
13.00 17.7 Data format setting No. 2
13.12 17.7 Data format setting No. 3
DOUBLE SIGNED
BINARY-TO-BCD
BDSL 473 4 13.74 16.3 Data format setting No. 0
13.58 16.4 Data format setting No. 1
13.79 16.5 Data format setting No. 2
13.75 16.6 Data format setting No. 3
GRAY CODE
CONVERSION
GRY 474 4 82.99 78.2 8-bit binary
81.67 80.6 8-bit BCD
98.65 90.4 8-bit angle
97.67 100.5 15-bit binary
98.99 114.5 15-bit BCD
110.67 112.9 15-bit angle
97.00 93.7 360° binary
108.33 99.7 360° BCD
113.00 92.3 360° angle
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
LOGICAL AND ANDW 034 4 0.30 27.0 ---
DOUBLE LOGICAL AND ANDL 610 4 0.60 28.3 ---
LOGICAL OR ORW 035 4 0.45 27.3 ---
DOUBLE LOGICAL OR ORWL 611 4 0.60 27.3 ---
EXCLUSIVE OR XORW 036 4 0.45 26.6 ---
DOUBLE EXCLUSIVE OR XORL 612 4 0.60 27.6 ---
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
