Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Special Math Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
EXCLUSIVE NOR XNRW 037 4 0.45 27.1 ---
DOUBLE EXCLUSIVE NOR XNRL 613 4 0.60 28.5 ---
COMPLEMENT COM 029 2 0.45 22.1 ---
DOUBLE COMPLEMENT COML 614 2 0.80 22.5 ---
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution
time (µs)
Conditions
CP1H CP1L
BINARY ROOT ROTB 620 3 43.99 44.3 ---
BCD SQUARE
ROOT
ROOT 072 3 49.32 43.6 ---
ARITHMETIC
PROCESS
APR 069 4 13.96 20.4 Designating SIN and COS
30.51 27.2 Designating line-segment approximation
FLOATING POINT
DIVIDE
FDIV 079 4 222.90 169.6 ---
BIT COUNTER BCNT 067 4 29.70 43.5 Counting 1 word
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
