Instruction Execution Times and Number of Steps Section 4-1
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Clock Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Debugging Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Failure Diagnosis Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
CALENDAR ADD CADD 730 4 212.90 219.9 ---
CALENDAR SUBTRACT CSUB 731 4 176.23 223.3 ---
HOURS TO SECONDS SEC 065 3 34.19 37.0 ---
SECONDS TO HOURS HMS 066 3 40.95 44.1 ---
CLOCK ADJUSTMENT DATE 735 2 134.67 123.7 ---
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
TRACE MEMORY
SAMPLING
TRSM 045 1 201.33 30.3 Sampling 1 bit and 0 words
1.12
ms
158.7 Sampling 31 bits and 6 words
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
FAILURE ALARM FAL 006 3 23.24 27.3 Recording errors
266.57 406.7 Deleting errors (in order of priority)
817.17 610.7 Deleting errors (all errors)
305.33 410.0 Deleting errors (individually)
SEVERE FAILURE
ALARM
FALS 007 3 --- --- ---
FAILURE POINT
DETECTION
FPD 269 4 245.07 286.7 When executed
258.2 362.4 First time
317.73 363.1 When executed
316.4 400 First time
