Instruction Execution Times and Number of Steps Section 4-1
Other Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Block Programming Instructions
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
SET CARRY STC 040 1 0.15 10.0 ---
CLEAR CARRY CLC 041 1 0.15 10.2 ---
EXTEND MAXIMUM CYCLE
TIME
WDT 094 2 23.94 24.2 ---
SAVE CONDITION FLAGS CCS 282 1 14.97 17.5 ---
LOAD CONDITION FLAGS CCL 283 1 17.83 18.9 ---
CONVERT ADDRESS FROM CV FRMCV 284 3 31.03 29.1 ---
CONVERT ADDRESS TO CV TOCV 285 3 34.90 28.0 ---
Instruction Mnemonic Code Length (steps)
(See note.)
ON execution
time (µs)
Conditions
CP1H CP1L
BLOCK PROGRAM
BEGIN
BPRG 096 2 26.59 9.2 ---
BLOCK PROGRAM
END
BEND 801 1 24.19 6.4 ---
BLOCK PROGRAM
PAUS E
BPPS 811 2 18.13 7.2 ---
BLOCK PROGRAM
RESTART
BPRS 812 2 9.29 6.8 ---
CONDITIONAL
BLOCK EXIT
(Execution con-
dition) EXIT
806 1 23.33 8.0 EXIT condition satisfied
9.33 5.8 EXIT condition not satisfied
CONDITIONAL
BLOCK EXIT
EXIT (bit
address)
806 2 26.78 10.8 EXIT condition satisfied
11.47 8.4 EXIT condition not satisfied
CONDITIONAL
BLOCK EXIT (NOT)
EXIT NOT (bit
address)
806 2 26.74 9.0 EXIT condition satisfied
11.41 11.2 EXIT condition not satisfied
Branching IF (execution
condition)
802 1 7.4 4.0 IF true
13.5 6.6 IF false
Branching IF (relay num-
ber)
802 2 11.55 7.6 IF true
13.55 10.2 IF false
Branching (NOT) IF NOT (relay
number)
802 2 11.61 10.6 IF true
13.61 8.0 IF false
Branching ELSE 803 1 7.71 6.0 IF true
13.55 4.2 IF false
Branching IEND 804 1 13.58 4.6 IF true
7.49 6.1 IF false
ONE CYCLE AND
WAIT
WAIT (execu-
tion condition)
805 1 27.53 3.7 WAIT condition satisfied
6.15 9.3 WAIT condition not satisfied
ONE CYCLE AND
WAIT
WAIT (relay
number)
805 2 28.78 7.4 WAIT condition satisfied
9.82 10.8 WAIT condition not satisfied
ONE CYCLE AND
WAIT (NOT)
WAIT NOT
(relay number)
805 2 26.27 11.2 WAIT condition satisfied
9.78 7.8 WAIT condition not satisfied
