List of Instructions by Function Code Appendix B
342 LD <> DT LOAD TIME NOT
EQUAL
--- --- --- 215
342 OR <> DT OR TIME NOT EQUAL --- --- --- 215
343 AND < DT AND TIME LESS
THAN
--- --- --- 215
343 LD < DT LOAD TIME LESS
THAN
--- --- --- 215
343 OR < DT OR TIME LESS THAN --- --- --- 215
344 AND <= DT AND TIME LESS
THAN OR EQUAL
--- --- --- 215
344 LD <= DT LD TIME LESS THAN
OR EQUAL
--- --- --- 215
344 OR <= DT OR TIME LESS THAN
OR EQUAL
--- --- --- 215
345 AND > DT AND TIME GREATER
THAN
--- --- --- 215
345 LD > DT LOAD TIME GREATER
THAN
--- --- --- 215
345 OR > DT OR TIME GREATER
THAN
--- --- --- 215
346 AND >= DT AND TIME GREATER
THAN OR EQUAL
--- --- --- 215
346 LD >= DT LOAD TIME GREATER
THAN OR EQUAL
--- --- --- 215
346 OR >= DT OR TIME GREATER
THAN OR EQUAL
--- --- --- 215
350 AND TST AND BIT TEST --- --- --- 110
350 LD TST LOAD BIT TEST --- --- --- 110
350 OR TST OR BIT TEST --- --- --- 110
351 AND TSTN AND BIT TEST NOT --- --- --- 110
351 LD TSTN LOAD BIT TEST NOT --- --- --- 110
351 OR TSTN OR BIT TEST NOT --- --- --- 110
400 + SIGNED BINARY ADD
WITHOUT CARRY
@+ --- --- 337
401 +L DOUBLE SIGNED
BINARY ADD
WITHOUT CARRY
@+L --- --- 339
402 +C SIGNED BINARY ADD
WITH CARRY
@+C --- --- 341
403 +CL DOUBLE SIGNED
BINARY ADD WITH
CARRY
@+CL --- --- 343
404 +B BCD ADD WITHOUT
CARRY
@+B --- --- 345
405 +BL DOUBLE BCD ADD
WITHOUT CARRY
@+BL --- --- 346
406 +BC BCD ADD WITH
CARRY
@+BC --- --- 348
407 +BCL DOUBLE BCD ADD
WITH CARRY
@+BCL --- --- 349
410 – SIGNED BINARY
SUBTRACT WITHOUT
CARRY
@– --- --- 351
411 –L DOUBLE SIGNED
BINARY SUBTRACT
WITHOUT CARRY
@–L --- --- 353
412 –C SIGNED BINARY
SUBTRACT WITH
CARRY
@–C --- --- 357
413 –CL DOUBLE SIGNED
BINARY SUBTRACT
WITH CARRY
@–CL --- --- 359
Function code Mnemonic Instruction Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
