Omron CP - PROGRAMMING MANUAL 05-2007 - Page 1140

1107
List of Instructions by Function Code Appendix B
414 –B BCD SUBTRACT
WITHOUT CARRY
@–B --- --- 361
415 –BL DOUBLE BCD
SUBTRACT WITHOUT
CARRY
@–BL --- --- 363
416 –BC BCD SUBTRACT
WITH CARRY
@–BC --- --- 366
417 –BCL DOUBLE BCD
SUBTRACT WITH
CARRY
@–BCL --- --- 367
420 * SIGNED BINARY
MULTIPLY
@* --- --- 369
421 *L DOUBLE SIGNED
BINARY MULTIPLY
@*L --- --- 371
422 *U UNSIGNED BINARY
MULTIPLY
@*U --- --- 372
423 *UL DOUBLE UNSIGNED
BINARY MULTIPLY
@*UL --- --- 374
424 *B BCD MULTIPLY @*B --- --- 375
425 *BL DOUBLE BCD
MULTIPLY
@*BL --- --- 377
430 / SIGNED BINARY
DIVIDE
@/ --- --- 378
431 /L DOUBLE SIGNED
BINARY DIVIDE
@/L --- --- 380
432 /U UNSIGNED BINARY
DIVIDE
@/U --- --- 382
433 /UL DOUBLE UNSIGNED
BINARY DIVIDE
@/UL --- --- 384
434 /B BCD DIVIDE @/B --- --- 385
435 /BL DOUBLE BCD DIVIDE @/BL --- --- 387
448 FSTR FLOATING POINT TO
ASCII
@FSTR --- --- 516
449 FVAL ASCII TO FLOATING
POINT
@FVAL --- --- 521
450 FIX FLOATING TO 16-BIT @FIX --- --- 530
451 FIXL FLOATING TO 32-BIT @FIXL --- --- 532
452 FLT 16-BIT TO FLOATING @FLT --- --- 533
453 FLTL 32-BIT TO FLOATING @FLTL --- --- 534
454 +F FLOATING-POINT
ADD
@+F --- --- 484
455 –F FLOATING-POINT
SUBTRACT
@–F --- --- 486
456 *F FLOATING-POINT
MULTIPLY
@*F --- --- 488
457 /F FLOATING-POINT
DIVIDE
@/F --- --- 490
458 RAD DEGREES TO
RADIANS
@RAD --- --- 492
459 DEG RADIANS-TO
DEGREES
@DEG --- --- 493
460 SIN SINE @SIN --- --- 495
461 COS COSINE @COS --- --- 496
462 TAN TANGENT @TAN --- --- 498
463 ASIN ARC SINE @ASIN --- --- 500
464 ACOS ARC COSINE @ACOS --- --- 502
465 ATAN ARC TANGENT @ATAN --- --- 503
466 SQRT SQUARE ROOT @SQRT --- --- 505
467 EXP EXPONENT @EXP --- --- 507
468 LOG LOGARITHM @LOG --- --- 509
Function code Mnemonic Instruction Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
