1108
List of Instructions by Function Code Appendix B
470 BINS SIGNED BCD-TO-
BINARY
@BINS --- --- 419
471 BCDS SIGNED BINARY-TO-
BCD
@BCDS --- --- 424
472 BISL DOUBLE SIGNED
BCD-TO-BINARY
@BISL --- --- 422
473 BDSL DOUBLE SIGNED
BINARY-TO-BCD
@BDSL --- --- 427
474 GRY GRAY CODE
CONVERSION
@GRY --- --- 430
486 SCL2 SCALING 2 @SCL2 --- --- 656
487 SCL3 SCALING 3 @SCL3 --- --- 660
490 CMND DELIVER COMMAND @CMND --- --- 876
498 MOVL DOUBLE MOVE @MOVL --- --- 250
499 MVNL DOUBLE MOVE NOT @MVNL --- --- 251
502 BCMP2 EXPANDED BLOCK
COMPARE
@BCMP2 --- --- 238
510 CJP CONDITIONAL JUMP --- --- --- 157
511 CJPN CONDITIONAL JUMP --- --- --- 157
512 FOR FOR-NEXT LOOPS --- --- --- 163
513 NEXT FOR-NEXT LOOPS --- --- --- 163
514 BREAK BREAK LOOP --- --- --- 166
515 JMP0 MULTIPLE JUMP --- --- --- 161
516 JME0 MULTIPLE JUMP END --- --- --- 161
517 MILH MULTI-INTERLOCK
DIFFERENTIATION
HOLD
--- --- --- 140
518 MILR MULTI-INTERLOCK
DIFFERENTIATIONRE
LEASE
--- --- --- 140
519 MILC MULTI-INTERLOCK
CLEAR
--- --- --- 140
520 NOT NOT --- --- --- 108
521 UP CONDITION ON --- --- --- 109
522 DOWN CONDITION OFF --- --- --- 109
530 SETA MULTIPLE BIT SET @SETA --- --- 124
531 RSTA MULTIPLE BIT RESET @RSTA --- --- 124
532 SETB SINGLE BIT SET @SETB --- !SETB 127
533 RSTB SINGLE BIT RESET @RSTB --- !RSTB 127
534 OUTB SINGLE BIT OUTPUT @OUTB --- !OUTB 130
540 TMHH ONE-MS TIMER --- --- --- 178
542 TIML LONG TIMER --- --- --- 184
543 MTIM MULTI-OUTPUT
TIMER
--- --- --- 187
545 CNR RESET TIMER/
COUNTER
@CNR --- --- 200
546 CNTX COUNTER --- --- --- 193
547 CNRX RESET TIMER/
COUNTER
--- --- --- 200
548 CNTRX REVERSIBLE
COUNTER
--- --- --- 196
550 TIMX TIMER --- --- --- 170
551 TIMHX HIGH-SPEED TIMER --- --- --- 174
552 TMHHX ONE-MS TIMER --- --- --- 178
553 TIMLX LONG TIMER --- --- --- 184
554 MTIMX MULTI-OUTPUT
TIMER
--- --- --- 187
Function code Mnemonic Instruction Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
