Symbol Math Instructions Section 3-10
Applicable Program Areas
Operand Specifications
Description /B(434) divides the BCD content of Dd by those of Dr and outputs the quotient
to R and the remainder to R+1.
Flags
Precautions If Dd or Dr are not BCD or if the remainder (R+1) is 0, an error will be gener-
ated and the Error Flag will turn ON.
If as a result of the division, the content of R is 0000 hex, the Equals Flag will
turn ON.
If as a result of the division, the leftmost bit of R is 1, the Negative Flag will
turn ON.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
Area Dd Dr R
CIO Area CIO 0 to CIO 6143 CIO 0 to
CIO 6142
Work Area W0 to W511 W0 to W510
Holding Bit Area H0 to H511 H0 to H510
Auxiliary Bit Area A0 to A959 A448 to A958
Timer Area T0000 to T4095 T0000 to T4094
Counter Area C0000 to C4095 C0000 to C4094
DM Area D0 to D32767 D0 to D32766
Indirect DM addresses
in binary
@ D0 to @ D32767
Indirect DM addresses
in BCD
*D0 to *D32767
Constants #0000 to #9999
(BCD)
#0001 to #9999
(BCD)
---
Data Registers DR0 to DR15 ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
R + 1 R
(BCD)
(BCD)
(BCD)
÷
Dd
Dr
Remainder Quotient
Name Label Operation
Error Flag ER ON when Dd is not BCD.
ON when Dr is not BCD.
ON when the remainder is 0.
OFF in all other cases.
Equals Flag = ON when R is 0.
OFF in all other cases.
To Next Page
