3-17-6 TIME-PROPORTIONAL OUTPUT: TPO(685)
Purpose Inputs the duty ratio or manipulated variable from the specified word, converts
the duty ratio to a time-proportional output based on the specified parameters,
and outputs the result from the specified output.
Ladder Symbol
Variations
Applicable Program Areas
–100
0.00
D100
D200
D300
C: D200
D201
Decimal values
Negative bias
Positive bias
Contents of D300
Contents of D200
TPO
S
C
R
S: Input word
C: First parameter word
R: Pulse output bit
Variations Executed Each Cycle for ON Condition TPO(685)
Executed Once for Upward Differentiation Not supported.
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
Block program areas Step program areas Subroutines Interrupt tasks
Not allowed OK OK OK
