Omron CP - PROGRAMMING MANUAL 05-2007 - Page 791

758
Step Instructions Section 3-21
Examples Sequential Control
0.00
0.01
0.02
W0.00
W0.00
W0.01
W0.01
W100.00
Step (A) ladder program
Step (B) ladder program
Normal ladder program
CIO 0.00 turns ON, step W0.00 starts
Step W0.00 starts from the next instruction
Step W0.00
W0.00 turns OFF, W0.01 turns ON and step W0.01 starts
Step W0.01 starts from the next instruction
W0.01 turns OFF and dummy bit W100.00 turns ON
End of step programming area
Step W0.01
W0.00
W0.01
W0.02
Step (A)
Step (B)
Step (C)
End
0.01 (Step (A) starting condition)
0.02 (Step (A)
→ Step (B) transition condition)
0.03 (Step (B)
→ Step (C) transition condition)
0.04 (Step (C) reset conditions)
