Network Instructions Section 3-24
CP1H and CP1L M (30 or 40 I/O points) CPU Unit Serial Commu-
nications Option Board Ports
CP1L L (14 or 20 I/O points) CPU Unit Serial Communications
Option Board Ports
CJ-series Serial Communication Unit Ports
(4) When specifying the serial port without a routing table for the serial gate-
way function (conversion to host link FINS), set the serial port’s unit ad-
dress in the destination network address byte.
(5) The unit address indicates the Unit, as shown in the following table.
(6) The maximum node number depends on the network being used. For a
Controller Link, the allowed range is 00 to 20 hexadecimal (0 to 32). Set
the destination node number to FF to broadcast to all nodes; set it to 00
to transmit within the local node.
Port Port’s unit address
Port 1 FD hex (253 decimal)
Port 2 FC hex (252 decimal)
Port Port’s unit address
Port 1 FC hex (252 decimal)
Port Port’s unit address Example: Unit number = 1
Port 1 80 hex + 4 × unit number 80 + 4 × 1 = 84 hex (132 decimal)
Port 2 81 hex + 4 × unit number 81 + 4 × 1 = 85 hex (133 decimal)
Unit Unit address setting
CP1H CPU Unit (Serial Com-
munications Option Board) or
CJ-series CPU Unit
00 hex
CS/CJ-series CPU Bus Unit 10 hex + unit number
CS/CJ-series Special I/O Unit 20 hex + unit number
CS-series Inner Board E1 hex
Computer 01 hex
Unit connected to network
(not necessary to specify
Unit)
FE hex
Direct specification of the
serial port’s unit address
CP1H or CP1L M (30 or 40 I/O points) CPU Unit
Serial Communications Option Board ports
Port 1: FD hex (253 decimal)
Port 2: FC hex (252 decimal)
CP1L L (14 or 20 I/O points) CPU Unit Serial
Communications Option Board port
Port 1: FC hex (252 decimal)
CS/CJ-series Serial Communications Unit ports
Port 1: 80 hex + 4 × unit number
Port 2: 81 hex + 4 × unit number
CS-series Serial Communications Board ports
Port 1: E4 hex (228 decimal)
Port 2: E5 hex (229 decimal)
CS/CJ-series CPU Unit ports
Peripheral port: FD hex (253 decimal)
RS-232C port: FC hex (252 decimal)
