Failure Diagnosis Instructions Section 3-28
t
s
: Initial setting in T
t
a
: Measured time
t’
s
: New setting in T after teaching
(When t
a
> t
s
, t’
s
= t
a
× 1.5)
A598.00
CIO 200.00
CIO 1000.00
t'
s
(t
a
× 1.5)
No error generated.
Measured time: t
a
Teaching
FPD Teaching Bit
Execution condition
Diagnostic output
