77
CP1H CPU Unit Operation Section 2-3
Built-in Flash Memory Flash memory is built into the CP1H CPU Units. Data in the following areas is
automatically backed up to the flash memory whenever it is written in any way
other than by instructions in the user program, e.g., when the CX-Programmer
or PT is used to transfer or edit data, edit the program online, or transfer data
from a Memory Cassette.
• User program area
• Parameter area (PLC Setup, routing tables, and unit setups for CJ-series
CPU Bus Units)
The next time the power supply is turned ON, the data in the built-in flash
memory is automatically transferred to user memory (i.e., the user program
area and parameter area).
It is also possible to save data from data areas in I/O memory in the built-in
flash memory using operations from the CX-Programmer.
The symbol table, comment file, and program index file can be stored in the
comment memory in flash memory. When the program is transferred from the
CX-Programmer to the CPU Unit, function block program information is also
stored automatically in flash memory.
Note The BKUP indicator on the front of the CPU Unit will light whenever the built-in
flash memory is being written or the Memory Cassette is being accessed.
Never turn OFF the power supply to the CPU Unit when the BKUP indicator is
lit.
Memory Cassette Memory Cassettes can be used as required in system operation and mainte-
nance. For example, they can be used to save programs, data memory con-
tents, PLC Setup data, or I/O comments from the CX-Programmer. The
contents of a Memory Cassette can also be automatically transferred if
desired.
