Connecting CP-series Expansion Units and Expansion I/O Units Section 7-1
7-1 Connecting CP-series Expansion Units and Expansion I/O
Units
CP-series Expansion Units and Expansion I/O Units can be connected to the
CP1H. The combined maximum number of Expansion Units and Expansion I/
O Units that can be connected is seven. CPM1A-AD041 Analog Input Units,
CPM1A-DA041 Analog Output Units, and CPM1A-TS002 and CPM1A-TS102
Temperature Sensor Units are allocated four words in the I/O area, however,
so when any of these Units is included the total number of Expansion Units
and Expansion I/O Units must be reduced.
Number of I/O Words
Unit name Model Current
consumption (mA)
I/O words
5 VDC 24 VDC Input Output
Expansion
Units
Analog Input Unit CP1W-AD041
CPM1A-AD041
100 90 4 2
Analog Output Unit CP1W-DA041
CPM1A-DA041
80 124 --- 4
Analog I/O Unit CPM1A-MAD01 66 66 2 1
CP1W-MAD11
CPM1A-MAD11
83 110
Temperature Control Unit CP1W-TS001
CPM1A-TS001
40 59 2 ---
CP1W-TS101
CPM1A-TS101
54 73
CP1W-TS002
CPM1A-TS002
40 59 4 ---
CP1W-TS102
CPM1A-TS102
54 73
CompoBus/S I/O Link Unit CP1W-SRT21
CPM1A-SRT21
29 --- 1 1
DeviceNet I/O Link Unit CPM1A-DRT21 48 --- 2 2
Expansion
I/O Units
40-point I/O Unit CP1W-40EDR
CPM1A-40EDR
80 90 2 2
CP1W-40EDT
CPM1A-40EDT
160 ---
CP1W-40EDT1
CPM1A-40EDT1
160 ---
32-point Output Unit CP1W-32ER 49 131 --- 2
CP1W-32ET 113 ---
CP1W-32ET1 113 ---
20-point I/O Unit CP1W-20EDR1
CPM1A-20EDR1
103 44 1 1
CP1W-20EDT
CPM1A-20EDT
130 ---
CP1W-20EDT1
CPM1A-20EDT1
130 ---
16-point Output Unit CP1W-16ER
CPM1A-16ER
42 90 --- 2
CP1W-16ET 76 ---
CP1W-16ET1 76 ---
8-point Input Unit CP1W-8ED
CPM1A-8ED
18 --- 1 ---
8-point Output Unit CP1W-8ER
CPM1A-8ER
26 44 --- 1
CP1W-8ET
CPM1A-8ET
75 ---
CP1W-8ET1
CPM1A-8ET1
75 ---
Note CP1W-32ER/32ET/32ET1’s maximum number of simultaneously ON points is 24 (75%).
