Specifications Section 9-4
9-4 Specifications
Note If two CP1W-CIF41 Ethernet Option Boards are mounted in the CP1L/H system, the CP1W-
CIF41 mounted on option board slot 1 will be abnormal and ERR indicator will be ON, the CP1W-
CIF41 on option board slot 2 will work normally.
Item Specifications
Model number CP1W-CIF41
Type 100/10Base-TX (Auto-MDIX)
Applicable PLCs CP1L and CP1H PLCs
Unit classification CP1 option port unit
Mounting location CP1L and CP1H micro PLC option port
Number of Units that can be
mounted
1 set. (each type of CP1L and CP1H PLC can only mount 1 set Ethernet Option Board)
(See note.)
Size of Buffers 8K bytes
Transfer Media access method CSMA/CD
Modulation method Baseband
Transmission paths Star form
Baud rate 100 Mbit/s (100Base-TX) 10 Mbit/s (10Base-T)
• Half/full auto-negotiation for each port
• Link speed auto-sensing for each port
Transmission media • Unshielded twisted-pair (UDP) cable
Categories: 5, 5e
• Shielded twisted-pair (STP) cable
Categories: 100Ω at 5, 5e
• Unshielded twisted-pair (UDP) cable
Categories: 3, 4, 5, 5e
• Shielded twisted-pair (STP) cable
Categories: 100Ω at 3, 4, 5, 5e
Transmission Distance 100 m (distance between hub and node)
Current consumption (Unit) 130 mA max. at 5 V DC
Vibration resistance Conforms to JIS 0040.
10 to 57Hz: 0.075-mm amplitude, 57 to 150 Hz: acceleration 9.8 m/s
2
in X, Y, and Z
directions for 80 minutes each (sweep time: 8 minutes×10 sweeps = 80 minutes)
Shock resistance Conforms to JIS 0041.
147m/s
2
, 3 times each in X, Y, and Z directions
Ambient operating temperature 0 to 55°C
Ambient humidity 10% to 90% (with no condensation)
Atmosphere Must be free of corrosive gas.
Ambient storage temperature -20 to 75°C
Weight 23 g max.
Dimensions 36.4×36.4×28.2 mm (W×H×D)
