PLC Setup Appendix G
Input Constant Settings
Input Constant (0-17CH): Input Constant Settings for CIO 0 to CIO 17
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 0CH: CIO 0 8 ms
Default (8ms)
No filter (0 ms) When power is turned
ON
10 00 to 07 10 hex
0.5 ms 11 hex
1 ms 12 hex
2 ms 13 hex
4 ms 14 hex
8 ms 15 hex
16 ms 16 hex
32 ms 17 hex
2 1CH: CIO 1 Same as
above.
Same as above. Same as above. 10 08 to 15 Same as
above.
3 2CH: CIO 2 11 00 to 07
4 3CH: CIO 3 11 08 to 15
5 4CH: CIO 4 12 00 to 07
6 5CH: CIO 5 12 08 to 15
7 6CH: CIO 6 13 00 to 07
8 7CH: CIO 7 13 08 to 15
9 8CH: CIO 8 14 00 to 07
10 9CH: CIO 9 14 08 to 15
11 10CH: CIO 10 15 00 to 07
12 11CH: CIO 11 15 08 to 15
13 12CH: CIO 12 16 00 to 07
14 13CH: CIO 13 16 08 to 15
15 14CH: CIO 14 17 00 to 07
16 15CH: CIO 15 17 08 to 15
17 16CH: CIO 16 18 00 to 07
18 17CH: CIO 17 18 08 to 15
