234
Pulse Outputs Section 5-3
â–  Setting Input Functions in the PLC Setup
Input
terminal
block
Input operation High-speed counters Origin search
Word Bit Normal inputs Interrupt inputs Quick-response
inputs
High-speed counter
operation enabled. (Use
high speed counter @
Option selected.)
Pulse output origin
search function
enabled for pulse
outputs 0 to 3.
CIO 0 00 Normal input 0 Interrupt input 0 Quick-response input 0 --- Pulse 0: Origin input
signal
01 Normal input 1 Interrupt input 1 Quick-response input 1 High-speed counter 2 (phase-
Z/reset)
Pulse 0: Origin proxim-
ity input signal
02 Normal input 2 Interrupt input 2 Quick-response input 2 High-speed counter 1 (phase-
Z/reset)
Pulse output 1: Origin
input signal
03 Normal input 3 Interrupt input 3 Quick-response input 3 High-speed counter 0 (phase-
Z/reset)
Pulse output 1: Origin
proximity input signal
04 Normal input 4 --- --- High-speed counter 2 (phase-
A, increment, or count input)
---
05 Normal input 5 --- --- High-speed counter 2 (phase-
B, decrement, or direction
input)
---
06 Normal input 6 --- --- High-speed counter 1 (phase-
A, increment, or count input)
---
07 Normal input 7 --- --- High-speed counter 1 (phase-
B, decrement, or direction
input)
---
08 Normal input 8 --- --- High-speed counter 0 (phase-
A, increment, or count input)
---
09 Normal input 9 --- --- High-speed counter 0 (phase-
B, decrement, or direction
input)
---
10 Normal input 10 --- --- High-speed counter 3 (phase-
A, increment, or count input)
---
11 Normal input 11 --- --- High-speed counter 3 (phase-
B, decrement, or direction
input)
---
CIO 1 00 Normal input 12 Interrupt input 4 Quick-response input 4 High-speed counter 3 (phase-
Z/reset)
Pulse output 2: Origin
input signal
01 Normal input 13 Interrupt input 5 Quick-response input 5 --- Pulse output 2: Origin
proximity input signal
02 Normal input 14 Interrupt input 6 Quick-response input 6 --- Pulse output 3: Origin
input signal
03 Normal input 15 Interrupt input 7 Quick-response input 7 --- Pulse output 3: Origin
proximity input signal
04 to
11
Normal input 16
to 23
--- --- --- ---
